To configure Offline Mediation Controller to support ECE when both are installed on the same system:

1. Open the OMC_home/bin/UDCEnvironment file in a text editor.

2. Set the IS_OCECE_REQUIRED parameter to true. This enables Offline Mediation Controller to interface with ECE.

   IS_OCECE_REQUIRED=true

3. Set the OCECE_HOME_PATH parameter to the directory in which ECE is installed. For example:

   OCECE_HOME_PATH=/home/opt/OracleCommunications/ECE

4. Save and close the file.

5. Start Offline Mediation Controller. See "Starting Offline Mediation Controller" in Offline Mediation Controller Installation Guide.

A configuration block is used to set configuration values that are needed by the node. You can define only one configuration block in an NPL rule file.

Config {
PRODUCTTYPES "product_type[, ...]";
PAYLOAD "payload_type[, ...]";
PAYLOADDATATYPE "datatype";
USAGEOBJECTS "usage_object";
EVENT "event_type[, ...]";
VERSION "version_number[, ...]";
MODE "usage_request_mode";
TIME_ZONE "time_zone";
DATE_FORMAT "date_format";
USAGE_REQUEST_BUILDER "request_format";
}

PRODUCTTYPES "product_type[, ...]";

where product_type is a product type defined in ECE. This parameter is specific to the product types the ECE DC processes.

PAYLOAD "payload_type[, ...]";

where payload_type is the payload type defined in ECE.

PAYLOADDATATYPE "datatype";

where datatype specifies the data type used in payloads.

USAGEOBJECTS "usage_object";

where usage_object specifies the usage objects type. The default value is USAGEBUILDER.

EVENT "event_type[, ...]";

where event_type specifies the types of events. Add the event_type values separated by commas.

VERSION "version_number[, ...]";

where version_number specifies the version for each record corresponding to the product type. Add the version_number values separated by commas.

MODE "usage_request_mode";

where usage_request_mode specifies the mode in which Offline Mediation Controller sends usage requests to ECE. Set the parameter to one of the following values:

• CUMULATIVE: Specifies that the balance impact in ECE is cumulative.

• INCREMENTAL Specifies that the balance impact in ECE is incremental.

TIME_ZONE "time_zone";

where time_zone specifies the time zone used by the ECE DC to send the session start time and the session end time to ECE. The default value is UTC. The time zone is set at record level or at cartridge level:

• Record level: If the NPL output record block contains the timeZone field, the time zone is set at record level. For record level time zone, each call detail record (CDR) can have a different time zone defined by the timeZone field in the CDR.

• Cartridge level: If the configuration block contains TIME_ZONE field, the time zone is set at cartridge level. All the CDRs processed by the cartridge will contain the same time zone as defined by the TIME_ZONE field.

DATE_FORMAT "date_format";

where date_format specifies the date format used by ECE DC to send the session start time and the session end time to ECE. The default value is yyyy-MM-dd HH:mm:ss.

USAGE_REQUEST_BUILDER "request_format";

where request_format defines the usage request builders. This parameter is used to create the builders for the corresponding product type, event, and version.

For example:

Config {
PRODUCTTYPES "VOICE,DATA,SMS";
PAYLOAD "VOICE_USAGE_Terminate_PAYLOAD,VOICE_USAGE_Update_PAYLOAD,
VOICE_USAGE_Debit_unit_PAYLOAD,VOICE_USAGE_Refund_unit_PAYLOAD,
VOICE_USAGE_Refund_amount_PAYLOAD,VOICE_USAGE_Debit_amount_PAYLOAD,
DATA_DATA_USAGE_Terminate_PAYLOAD,DATA_DATA_USAGE_Update_PAYLOAD,
DATA_DATA_USAGE_Debit_unit_PAYLOAD,DATA_DATA_USAGE_Refund_unit_PAYLOAD,
DATA_DATA_USAGE_Refund_amount_PAYLOAD,DATA_USAGE_Debit_amount_PAYLOAD,
SMS_SMS_USAGE_Terminate_PAYLOAD,SMS_SMS_USAGE_Debit_unit_PAYLOAD,
SMS_SMS_USAGE_Refund_unit_PAYLOAD,SMS_SMS_USAGE_Refund_amount_PAYLOAD,
SMS_SMS_USAGE_Debit_amount_PAYLOAD";
PAYLOADDATATYPE "PAYLOADDATATYPE";
USAGEOBJECTS "USAGEBUILDER";
EVENT "USAGE,DATA_USAGE,SMS_USAGE";
VERSION "1.0";
MODE "CUMULATIVE";
TIME_ZONE "UTC";
DATE_FORMAT "yyyy-MM-dd HH:mm:ss";
USAGE_REQUEST_BUILDER "VOICE@USAGE@1.0,DATA@DATA_USAGE@1.0,SMS@SMS_USAGE@1.0";
}

An output record block is used to define the format of an output data record of the node.

OutputRec {
datatype parameter;
} out;

Where:

datatype is the data type of the output field; for example, String.

parameter is the output field name.

For example:

OutputRec {
                String calling_number;
                Integer seq_no;
                String duration;
                String start_time;
                String end_time;
                String product_type;
                String session_id;
                String CalledId;
                String npl_type;
                String cdr_service;
                String cell_id;
                String requestedInputVolume;
                String requestedOutputVolume;
                String requestedTotalVolume;
                String usedUnitsInputVolume;
                String usedUnitsOutputVolume;
                String usedUitsTotalVolume;
                Integer usedUnitsSpecificUnit;
                String eventType;
                String version;
                String operationType;
                String correlation_identifier;
                Integer balance_element_id;
                Double amount;
                //  String timeZone;
} out;

For every payload type in the configuration block, define an Expose block. In the Expose block, map the NPL fields to the ECE Payload fields defined in the ECE request specifications.

For example:

Expose for VOICE_PAYLOAD{out.CalledId "CALLED_ID";out.duration "REQUESTED_UNITS[0].DURATION";}
Expose for DATA_PAYLOAD{out.cell_id "CELL_ID";
out.requestedInputVolume "REQUESTED_UNITS[0].INPUT_VOLUME";
out.requestedOutputVolume "REQUESTED_UNITS[0].OUTPUT_VOLUME";
out.requestedTotalVolume "REQUESTED_UNITS[0].TOTAL_VOLUME";
out.usedUnitsInputVolume "USED_UNITS[0].INPUT_VOLUME";
out.usedUnitsOutputVolume "USED_UNITS[0].OUTPUT_VOLUME";
out.usedUitsTotalVolume "USED_UNITS[0].TOTAL_VOLUME";}

For every payload data type in the configuration block, define an Expose block. In the Expose block, define the data type for the fields that are passed in payload data type.

For example:

Expose for PAYLOADDATATYPE{out.duration "SECONDS";
out.requestedInputVolume "VOLUME";
out.requestedOutputVolume "VOLUME";
out.requestedTotalVolume "VOLUME";
out.usedUnitsInputVolume "VOLUME";
out.usedUnitsOutputVolume "VOLUME";
out.usedUitsTotalVolume "VOLUME";}

For every usage objects type in the configuration block, define an Expose block. In the Expose block, map the NPL fields that are sent as parameters in the create usage objects method.

For example:

Expose for USAGEBUILDER{
out.calling_number "PARAM1";
out.session_id "PARAM2";
out.start_time "PARAM3";
out.end_time "PARAM4";
out.seq_no "PARAM5";
}
