Monitor Environments and Environment Pools

Monitor environments and environment pools from within a project. Here, you can identify shared environment pools, find environments that require updates to the robot agent, and check whether an environment pool has enough environments to handle its robot instance load.

  1. In a project, open the Environment pools tab.
    1. In the navigation pane, select Projects.
    2. Select the project name.
    3. Select the Observe tab.
    4. In the left toolbar, select Robot Robot.
    5. Select the Environment pools tab.
  2. Find the information that you need on the page.

    The following table provides sample questions and how to find the answers on this page.

    Question How to find the answer

    Which environment pools are associated with the project?

    • Find the list of all environment pools in the table.

    Which environments are in an environment pool?

    1. In the table, select an environment pool.

      A page lists its environments, including their robot agent versions, host names, operating systems, and statuses.

    2. To view more details about each environment: Point to an environment, and in the Actions column, select Open Details Open details icon.

    Which environment pools are shared between projects?

    • Find an environment pool in the table.

      • When the environment pool is shared, Shared appears below its name.

      • If you don't see Shared, the environment pool isn't shared.

      One environment lists Outdated robot agents below its name. Another lists Shared below its name.

    Do any robot agents need to be updated?

    1. Find an environment pool in the table.

      • When at least one robot agent in an environment pool needs to be updated to the latest version, Outdated robot agents appears below the environment pool's name.

      • If this text doesn't appear, all robot agents in the pool are up to date.

      One environment lists Outdated robot agents below its name. Another lists Shared below its name.

    2. Select an environment pool with an outdated robot agent.

    3. In the Agent Version column, look for a robot agent with a caution symbol in front of it. When you point to the symbol, Outdated robot agents appears in a tooltip.

      Outdated robot agent appears in a tooltip on a robot agent's version

    Do any environment pools have queued robot instances because all environments are actively running robot instances?

    • Review the Utilization column:

      • 0% utilization indicates that no robot instances are running or queued for any environments.

      • 100% utilization or lower indicates that the environment pool is able to run all robot instances without adding any to a queue.

      • 101% utilization or higher indicates that at least one robot instance is unable to be run because all environments are busy running other robot instances.

        For example, if an environment pool has only one environment, and the environment is running one robot instance with two robot instances in its queue, its utilization is 300%.

        Utilization over 100% might indicate that the environment pool requires additional environments.

        The Utilization column lists two entries, one for 300% and another for 0%

    How many robot instances are in the queue for an environment pool?

    1. Find an environment pool for which the Utilization column shows a number above 100%, and select the row in the table.

    2. On the next page, view the Environment pool status section on the right, and find the Queued robot instances metric.

    Are any environments offline in an environment pool?

    • See the Status column, which lists the number of online and offline environments in each environment pool.

      Below the Status column, you can see the number of online and offline environments

    Which robots run on an environment pool?

    1. Select an environment pool in the table.

    2. In the Environment pool status area on the right, select View linked robots.
