8.2.4 Create JMS Connection Factory

Follow the below steps to create JMS connection factory.
  1. Login to WebLogic Server 12c console (http://hostname:port/console) by specifying the Weblogic administrator user name and password.
  2. Click Domain Name > Services > Messaging > JMS Modules. The main window displays the list of JMS modules available.
  3. Select the newly created JMS module OfsllJMSModule.
    The following window is displayed.

    Figure 8-27 JMS Connection Factory 1


    Description of Figure 8-27 follows
    Description of "Figure 8-27 JMS Connection Factory 1"

  4. Click New.
    The following window is displayed.

    Figure 8-28 JMS Connection Factory 2


    Description of Figure 8-28 follows
    Description of "Figure 8-28 JMS Connection Factory 2"

  5. Click Next.
    The following window is displayed.

    Figure 8-29 JMS Connection Factory 3


    Description of Figure 8-29 follows
    Description of "Figure 8-29 JMS Connection Factory 3"

  6. Select Connection Factory option and click Next.
    The following window is displayed.

    Figure 8-30 JMS Connection Factory 4


    Description of Figure 8-30 follows
    Description of "Figure 8-30 JMS Connection Factory 4"

  7. Specify the following details:
    • Enter the Name of the Connection Factory as OfsllJMSCF
    • Enter the JNDI Name as jms/OfsllJMSCF
    • Select the check box XA Connection Factory Enabled
  8. Click Next.
    The following window is displayed.

    Figure 8-31 JMS Connection Factory 5


    Description of Figure 8-31 follows
    Description of "Figure 8-31 JMS Connection Factory 5"

  9. Click Advanced Targeting.
    The following window is displayed.

    Figure 8-32 JMS Connection Factory 6


    Description of Figure 8-32 follows
    Description of "Figure 8-32 JMS Connection Factory 6"

  10. Select the Subdeployments as OfsllJMSSD from the drop down list.
  11. Under JMS Servers, select the check box against ofsllJMSServer.
  12. Click Finish to save and activate the changes. Once done, the following window is displayed.

    Figure 8-33 JMS Connection Factory 7


    Description of Figure 8-33 follows
    Description of "Figure 8-33 JMS Connection Factory 7"
