1.3.1 US CHIPS Outbound Transaction Input Detailed

On Homepage, specify PSDOCHNL in the text box, and click next arrow.
US CHIPS Outbound Transaction Input Detailed screen is displayed

Figure 1-7 US CHIPS Outbound Transaction Input Detailed

Description of "Figure 1-7 US CHIPS Outbound Transaction Input Detailed"
.

On the detailed screen of the US CHIPS Outbound Transaction Input, specify the fields.

For more information about the fields, refer to field description below:

Table 1-4 US CHIPS Outbound Transaction Input Detailed - Field Description

Field	Description
Host Code	System displays the Host Code of selected branch of the logged in user on clicking ‘New’ button.
Transaction Branch	System displays the Transaction Branch of selected branch of the logged in user on clicking ‘New’ button.
Source Code	Specify the Source Code from the list of values.
Network Code	Specify the Network Code from the list of values.
Transaction Identification	System displays the Transaction Identification of selected branch of the logged in user on clicking ‘New’ button.
Source Reference Number	Specify the Source Reference Number.
Related Reference Number	System displays the Related Reference Number of selected branch of the logged in user on clicking ‘New’ button.
Transfer Type	Select the Transfer Type from the following: Bank Transfer Customer Transfer

Main Tab
Other Details Tab
Charges Information Tab
Enrich / Validations
FI Information Button
Remittance Information Button
UDF Button
This topic provides details of the Fields screen.
MIS Button
This topic explains the MIS Details screen.
All Messages
Accounting Entries
This topic provides the systematic instructions to process the Accounting Entries screen.
US CHIPS Outbound Transaction Input Detailed Summary

Parent topic: Outbound Transaction Screens
